Industrial Motors

Baldor Electric D2525R, 25 Hp, 1750/2300 Rpm, MC2812ATZ Fr, 150 Field, 240 Arm, TEFC, Rigid Base, Shunt Wound Motor

Baldor Electric D2525R, 25 Hp, 1750/2300 Rpm, MC2812ATZ Fr, 150 Field, 240 Arm, TEFC, Rigid Base, Shunt Wound Motor

$29,797.66
$29,797.66
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.

D2525R, 25 Hp, 1750/2300 Rpm, MC2812ATZ Fr, 150 Field, 240 Arm, TEFC, Rigid Base, Shunt Wound Motor

Engineering Data

Armature Voltage 240 V
Base Speed 1,750 rpm
Field Voltage 150 V
Frame MC2812ATZ
Frame Material Exposed Laminations
Output Power 25 hp
Brand Baldor-Reliance
Agency Approvals CCSA US
Ambient Temperature 40 °C
Armature Current 87.0 A
Bearing Grease Type POLYREX EM (-20F +300F)
Drip Cover No Drip Cover
Duty Rating CONT
Feedback Device No feedback
Field Winding Type STAB SHUNT
Frame Prefix MC
Heater Indicator No heater
Insulation Class F
Lifting Lugs Standard Lifting Lugs
Motor Standards NEMA
Overall Length 41.62 in
Service Factor 1.00
Shaft Diameter 2.374 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Slinger Indicator No Slinger

View full details
