Baldor Electric ECP64314TR-4 60 Hp, 1800 Rpm, 364T Fr, 460 Vac, 3 PH, TEFC, Foot Mounted, IEEE 841, Severe Duty Motor

ECP64314TR-4 60 Hp, 1800 Rpm, 364T Fr, 460 Vac, 3 PH, TEFC, Foot Mounted, IEEE 841, Severe Duty Motor

Engineering Data

Output 60.000 hp
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60.00 Hz
Voltage 460 V
Frame Material Iron
Frame 364T
XP Class and Group NONE
XP Division Division II
Brand Baldor-Reliance
Agency Approvals CCSA US
CSA EEV
UR
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Base Indicator Rigid
Bearing Grease Type MOBIL SHC 220 (ATHENS ONLY)
Constant Torque Speed Range 10-60
Current 68.0 A
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 95.0%
Feedback Device No feedback
Heater Indicator No heater
High Voltage Full Load Amps 68.0 A
Insulation Class F
Inverter Code Inverter ready
KVA Code G
Lifting Lugs No Lifting Lugs
Motor Lead Quantity/Wire Size 3 @ 4 AWG
Motor Standards None
Motor Type A36062M
Number of Poles 4
Overall Length 33.48 in
Power Factor 87
Pulley End Bearing Type Roller
Pulley Face Code Standard
Service Factor 1.15
Shaft Diameter 2.375 in
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Phase Seq-Std Rot (CCWODE)
Shaft Slinger Indicator No Slinger
Speed 1,780 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing None
Thermal Device - Winding None
XP Temp Code T3
