Baldor Electric ECR91004T-4 100 Hp, 1800 Rpm, 405T FR, 460 Vac, 3 PH, TEFC, Foot Mounted, Crusher Motor

ECR91004T-4 100 Hp, 1800 Rpm, 405T FR, 460 Vac, 3 PH, TEFC, Foot Mounted, Crusher Motor

Engineering Data

Output 100.000 hp
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60.00 Hz
Voltage 460 V
Frame Material Iron
Frame 405T
XP Class and Group NONE
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals CSA EEV
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Constant Torque Speed Range 6-60
Current 115.0 A
Design Code A
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 95.4%
Feedback Device No feedback
Heater Indicator No heater
High Voltage Full Load Amps 115.0 A
Insulation Class F
Inverter Code Inverter ready
KVA Code H
Lifting Lugs Standard Lifting Lugs
Max Speed 3,600 rpm
Motor Lead Quantity/Wire Size 3 @ 1 AWG
Motor Standards NEMA
Motor Type A40076M
Number of Poles 4
Overall Length 38.04 in
Power Factor 85
Product Family CRUSHER / CHIPPER
Pulley End Bearing Type Ball
Pulley Face Code Standard
Service Factor 1.25
Shaft Diameter 2.875 in
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator Shaft Slinger
Speed 1,785 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing NONE (OLD)
Thermal Device - Winding None
