Baldor Electric EM3609, 2 Hp, 1800 Rpm, 184 FR, 230/460 Vac, 3 PH, TEFC, Foot Mounted, General Purpose Motor

EM3609, 2 Hp, 1800 Rpm, 184 FR, 230/460 Vac, 3 PH, TEFC, Foot Mounted, General Purpose Motor

Engineering Data

Output 2.000 hp
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60 Hz
Voltage 230 V 460 V
Frame Material Steel
Frame 184
XP Class and Group NONE
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals
CSA CSA EEV
UR
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current
6.6 A @ 208 V
5.8 A @ 230 V
2.9 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 86.5%
Electrically Isolated Bearing
Not Electrically Isolated
Feedback Device
No feedback
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 2.9 A
Insulation Class F
Inverter Code
Inverter ready
KVA Code L
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator
No Locked Bearing
Motor Lead Exit
KO Box
Motor Lead Quantity/Wire Size
9 @ 18 AWG
Motor Lead Termination
Flying Leads
Motor Standards
NEMA
Motor Type 3528M
Number of Poles 4
Overall Length 13.76 in
Power Factor 75
Product Family
General Purpose
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 0.875 in
Shaft Extension Location Pulley End
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Shaft Slinger Indicator No Slinger
Speed 1,755 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
