Baldor Electric EM7083T-I, 30 Hp, 3600 Rpm, 286TS FR, 230/460 Vac, 3 PH, TEFC, Foot Mounted, Explosion Proof Motor.

EM7083T-I, 30 Hp, 3600 Rpm, 286TS FR, 230/460 Vac, 3 PH, TEFC, Foot Mounted, Explosion Proof Motor.

Engineering Data

Output 25.000 hp @ 50 Hz
30.000 hp @ 60 Hz
Phase 3
Synchronous Speed 3,600 rpm
Frequency 50.00 Hz
60.00 Hz
Voltage 190 V @ 50 Hz
380 V @ 50 Hz
230 V @ 60 Hz
460 V @ 60 Hz
Frame Material Iron
Frame 286TS
XP Class and Group Class I, Group C & D
XP Division Division I
Brand Baldor-Reliance
Agency Approvals CSA
CSA EEV
UL
UR
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 68.0 A @ 190 V
72.0 A @ 208 V
66.0 A @ 230 V
34.0 A @ 380 V
33.0 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 91.7%
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device No feedback
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 33.0 A
Insulation Class F
Inverter Code Not inverter
KVA Code G
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit KO Box
Motor Lead Quantity/Wire Size 9 @ 10 AWG
Motor Lead Termination Flying Leads
Motor Standards NEMA
Motor Type 1046M
Number of Poles 2
Overall Length 27.23 in
Power Factor 90
Product Family General Purpose
Pulley End Bearing Type Sealed Bearing
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status RoHS Non-Compliant
Service Factor 1.15
Shaft Diameter 1.625 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator Shaft Slinger
Speed 3,520 rpm
2,920 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing NONE (OLD)
Thermal Device - Winding Normally Closed Thermostat
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
XP Temp Code T3C
