Baldor Electric EMVM3554D, 1.1 KW / 1.5 Hp, 1800 Rpm, D90SD FR, 230/460 Vac, 3 PH, TEFC (IP54), (IEC-B5), Flange Mounted, IEC Metric Motor

EMVM3554D, 1.1 KW / 1.5 Hp, 1800 Rpm, D90SD FR, 2230/460 Vac, 3 PH, TEFC (IP54), (IEC-B5), Flange Mounted, IEC Metric Motor

Engineering Data

Output 1.100 kW
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60 Hz
Voltage 208 V
230 V
460 V
Enclosure TEFC
Frame Material Steel
Frame D90SD
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals CE
CSA
UR
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator No Mounting
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 5.1 A @ 208 V
4.8 A @ 230 V
2.4 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 84.0%
Electrically Isolated Bearing No electrically isolated
Feedback Device No feedback
Frame Prefix D
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 2.4 A
Insulation Class F
Inverter Code Not inverter
KVA Code M
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit KO Box
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Standards IEC
Motor Type 3521M
Mounting Arrangement B5
Number of Poles 4
Overall Length 12.99 in
Power Factor 70
Product Family General Purpose
Pulley End Bearing Type Ball Bearing
Pulley Face Code D-Flange
Pulley Shaft Indicator Tapped & Key
Rodent Screen No Rodent Screen
Service Factor 1.15
Shaft Diameter 0.945 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1,755 rpm
Speed Code Single Speed
Starting Method DOL
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
