Baldor Electric EMVM3611D 2.2 KW / 3.0 Hp, 1800RPM, D100LD FR, 230/460 Vac, 3 PH, TEFC (IP54), (IEC-B5), Flange Mounted, IEC Metric Motor

EMVM3611D 2.2 KW / 3.0 Hp, 1800RPM, D100LD FR, 230/460 Vac, 3 PH, TEFC (IP54), (IEC-B5), Flange Mounted, IEC Metric Motor

Engineering Data

Output 2.200 kW
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60.00 Hz
Voltage 230 V
460 V
Frame Material Steel
Frame D100D
XP Class and Group NONE
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals CE
CSA EEV
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator No Mounting
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 9.0 A @ 208 V
8.4 A @ 230 V
4.2 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 89.5%
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device No feedback
Frame Prefix D
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 4.2 A
Insulation Class F
Inverter Code Not inverter
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit KO Box
Motor Lead Quantity/Wire Size 9 @ 16 AWG
Motor Lead Termination Flying Leads
Motor Standards IEC
Motor Type 3632M
Number of Poles 4
Overall Length 17.91 in
Power Factor 75
Product Family General Purpose
Pulley End Bearing Type Ball
Pulley Face Code D-Flange
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 1.103 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1,760 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing NONE (OLD)
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
