Baldor Electric EMVM3710D, 5.5K W/7.5 HP, 1800 Rpm, D132 FR, 230/460 Vac,3 PH, TEFC (IP54), (IEC-B5), Flange Mounted, IEC Metric Motor

EMVM3710D, 5.5K W/7.5 HP, 1800 Rpm, D132 FR, 230/460 Vac,3 PH, TEFC (IP54), (IEC-B5), Flange Mounted, IEC Metric Motor.

Engineering Data

Output 7.500 hp
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60.00 Hz
Voltage 230 V
460 V
Frame Material Steel
Frame D132SD
XP Class and Group NONE
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals CE
CSA EEV
Ambient Temperature 50 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator No Mounting
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 20.0 A @ 208 V
19.0 A @ 230 V
9.5 A @ 460 V
Design Code A
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 91.7%
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device No feedback
Frame Prefix D
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 9.5 A
Insulation Class F
Inverter Code Not inverter
KVA Code J
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit KO Box
Motor Lead Quantity/Wire Size 9 @ 14 AWG
Motor Lead Termination Flying Leads
Motor Standards IEC
Motor Type 3738M
Number of Poles 4
Overall Length 20.48 in
Power Factor 81
Product Family General Purpose
Pulley End Bearing Type Ball
Pulley Face Code D-Flange
Pulley Shaft Indicator Tapped & Key
Rodent Screen None
RoHS Status RoHS Compliant
Service Factor 1.00
Shaft Diameter 1.497 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1,770 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing NONE (OLD)
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
