Baldor Electric FSWDM41903T 25 Hp, 1800 Rpm, 284T Fr, 230/460 Vac, 3 PH, TEFC, Foot Mounted, Encapsulated, Food Safe Stainless Steel

FSWDM41903T 25 Hp, 1800 Rpm, 284T Fr, 230/460 Vac, 3 PH, TEFC, Foot Mounted, Encapsulated, Food Safe Stainless Steel

Engineering Data

Output 25.000 hp
Phase 3
Synchronous Speed 1,800 rpm
Frequency 60.00 Hz
Voltage 460 V
230 V
Frame Material Stainless Steel
Frame 284T
Brand Baldor-Reliance
Agency Approvals CSA
UR
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 60.0 A @ 230 V
30.0 A @ 460 V
Design Code A
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 93.6%
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device No feedback
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 30.0 A
Insulation Class H
Inverter Code Inverter ready
KVA Code H
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Quantity/Wire Size 9 @ 10 AWG
Motor Lead Termination Flying Leads
Motor Standards NEMA
Motor Type 4068M
Number of Poles 4
Overall Length 28.14 in
Power Factor 84
Product Family WD All SD Non-Encapsulated
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status RoHS Compliant
Service Factor 1.15
Shaft Diameter 1.875 in
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1,775 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
