Industrial Motors

Baldor Electric GCP24234 1/15 Hp, 115 Vac, 1 PH, 27 Rpm, 60:1, 167 Lb-in, 2424C-PSM Frame, Parallel Shaft AC Gearmotor

Baldor Electric GCP24234 1/15 Hp, 115 Vac, 1 PH, 27 Rpm, 60:1, 167 Lb-in, 2424C-PSM Frame, Parallel Shaft AC Gearmotor

$365.00
$365.00
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.
AC Parallel Shaft Gearmotors is no longer manufacturing this motor, possible replacement is the following AC Parallel Shaft Gearmotors part# 1027

**This motor is no longer being manufactured, possible replacement is Bodine Model# 1027**

GCP24234 1/15 Hp, 115 Vac, 1 PH, 27 Rpm, 60:1, 167 Lb-in, 2424C-PSM Frame, Parallel Shaft AC Gearmotor Engineering Data Enclosure TENV Frequency 50.00 Hz 60.00 Hz Gear Ratio 60:1 Gear Style PSM Gearhead Type PARALLEL SHAFT Number of Poles 4 Output Speed 23 rpm 27 rpm Output Torque 167.00 lb-in Phase 1 Speed 1340 rpm 1650 rpm Voltage 115 V Capacitor Size 15 Connection Diagram CD1018 Dimensional Drawing Numbers 24E312W009G2 Duty Rating CONT Frame Material Steel Insulation Class F KVA Code

View full details

Attachments
