Baldor Electric GMP3340, 1/2 Hp, 208-230/460 Vac, 43 Rpm, 40:1, 627 Lb-in., 3320M-PSLH Frame, 3 Phase Input, AC Gearmotor

**Baldor is no longer manufacturing this motor, possible replacement is Bodine Model# 2860**
GMP3330, 1/3 Hp, 208-230/460 Vac, 57 Rpm, 30:1, 320 Lb-in., 3320M-PSLH Frame, 3 Phase Input, AC Gearmotor

Engineering Data

Catalog Number GMP3330
Enclosure TEFC
Frame Material Steel
Frequency 60.00 Hz
Output @ Frequency .330 HP @ 60 HZ
Phase 3
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Voltage @ Frequency 460.0 V @ 60 HZ
230.0 V @ 60 HZ
208.0 V @ 60 HZ
Agency Approvals CSA
UR
Ambient Temperature 40 °C
Current @ Voltage .700 A @ 460.0 V
1.400 A @ 230.0 V
1.500 A @ 208.0 V
Design Code B
Duty Rating CONT
Efficiency @ 100% Load 74.0 %
Feedback Signal NONE
High Voltage Full Load Amps 0.7 a
Heater Indicator No Heater
Insulation Class B
Inverter Code Not Inverter
KVA Code -
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Type 3320M
Number of Poles 4
Power Factor 58
Product Family General Purpose
RoHS Status ROHS COMPLIANT
Service Factor 1.00
Shaft Diameter 0.393 IN
Shaft Rotation Reversible
Speed 1725 rpm
Motor Standards NEMA
Starting Method Full Voltage
Thermal Device - Winding None
Winding Thermal 1 None
Winding Thermal 2 None
