Baldor Electric GPP12541, 1/8 Hp, 90 VDC, 250 Rpm, 10:1, 30 Lb-in., 2416P-PSM Frame, Parallel Shaft DC Gearmotor

**This motor is no longer being manufactured, possible replacement is Bodine Model# 1250**

GPP12541, 1/8 Hp, 90 VDC, 250 Rpm, 10:1, 30 Lb-in., 2416P-PSM Frame, Parallel Shaft DC Gearmotor Engineering Data Catalog Number: GPP12541 Specification Number: 30977B Phase: DC Voltage: 90 Output RPM: 250 Torque: 30 Ratio: 10 Amps: 1.34 Insulation: A Rotation: R Enclosure: TENV Type: 125P Mechanical Specification Number: 24A099Z026G2 Electrical Specification Number: Differences The mounting of the Bodine model is similar, but not exact to that of the Baldor model. The Bodine model has threaded mounting holes in the face of the gearbox, whereas the Baldor model has unthreaded "flange-style" mounting holes. The user has to compare drawings and decide if the Bodine model can be used. The Baldor model also has mounting holes in the base of the gearbox. If those are being used, then adding Bodine model 0970 mounting bracket will achieve a similar, but not exact, mounting configuration.
