Industrial Motors

Century Electric DC101, 1/6 Hp, 1200 Rpm, 34 FR, 230 Vac, TENV, Rigid Base, General Purpose Motor.

Century Electric DC101, 1/6 Hp, 1200 Rpm, 34 FR, 230 Vac, TENV, Rigid Base, General Purpose Motor.

$627.00
$627.00
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.
$627.00 $595.65
Sale

DC101, 1/6 Hp, 1200 Rpm, 34 FR, 230 Vac, TENV, Rigid Base, General Purpose Motor.

General Specifications

Output HP:1/6 Hp
Output KW:0.13 kW
Voltage:230 V
Current:0.7 A
Speed:1140 rpm
Service Factor:1
Duty:Continuous
Insulation Class:F
Frame:34
Enclosure:Totally Enclosed Non Ventilated
Thermal Protection:No
Ambient Temperature:40 °C
UL:Recognized
CSA:Y
CE:N
Technical Specifications
Electrical Type:DC Permanent Magnet
Starting Method:Across The Line
Rotation:Reversible
Mounting:Rigid base
Drive End Bearing:Ball
Opp Drive End Bearing:Ball
Frame Material:Rolled Steel
Shaft Type:Flat
Overall Length:9.82 in
Frame Length:6.06 in
Shaft Diameter:0.500 in
Shaft Extension:1.62 in

View full details

Attachments
