Baldor Electric CM7047T,7 1/2 Hp, 1800 Rpm, 213TC FR, 230/460 Vac, 3 PH, TEFC, C-Face with Base, No Drip Cover, Explosion Proof Motor

**This motor has been replaced by Model# CEM7047T**
CM7047T,7 1/2 Hp, 1800 Rpm, 213TC FR, 230/460 Vac, 3 PH, TEFC, C-Face with Base, No Drip Cover, Explosion Proof Motor.

Engineering Data

Catalog Number CM7047T
Enclosure TEFC
Frame 213TC
Frequency 50 Hz
60 Hz
Output @ Frequency 7.500 HP @ 60 HZ
5.000 HP @ 50 HZ
Phase 3
Synchronous Speed @ Frequency 1500 RPM @ 50 HZ
1800 RPM @ 60 HZ
Voltage @ Frequency 460.0 V @ 60 HZ
380.0 V @ 50 HZ
190.0 V @ 50 HZ
230.0 V @ 60 HZ
XP Division Not Applicable
Agency Approvals UL
CSA
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Current @ Voltage 10.100 A @ 460.0 V
17.400 A @ 190.0 V
20.200 A @ 230.0 V
8.700 A @ 380.0 V
Design Code A
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 89.5 %
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device NO FEEDBACK
High Voltage Full Load Amps 8.7 a
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No Heater
Insulation Class B
Inverter Code Not Inverter
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Termination Flying Leads
Motor Lead Quantity/Wire Size 9 @ 14 AWG
Motor Type 3731M
Mounting Arrangement F1
Number of Poles 4
Overall Length 21.08 IN
Power Factor 77
Product Family General Purpose
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.00
Shaft Diameter 1.375 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1470 rpm
1770 rpm
Speed Code Single Speed
Motor Standards NEMA
Starting Method Direct on line
Thermal Device - Bearing None
Thermal Device - Winding Normally Closed Thermostat
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
XP Temp Code T3C
