E110382.00, 3/4 HP, 1200 RPM, 56C FR, DP, 115/208-230 Vac, 1 PH, C-Face Less Base, Capacitor Start, General Purpose

E110382.00, 3/4 HP, 1200 RPM, 56C FR, DP, 115/208-230 Vac, 1 PH, C-Face Less Base, Capacitor Start, General Purpose.

Engineering Data
Volts 115 Volts 230 Volts
F.L. Amps 6.50 F.L. Amps 3.25 F.L. Amps
S. F Amps 8.6 S. F Amps 4.3 S. F Amps

RPM 1200 Hertz 60
HP 3/4 Duty CONTINUOUS TYPE CD
KW 0.56
Frame 56C Serv. Factor 1.25 Phase 1
Max Amb 40 Design L Code E
Insul Class F Protection NOT Therm.Prot.
Eff 100% 80.3 Eff 75% PF 93.0
UL Y-(LEESON UL REC) CSA No Bearing OPE
CC Number EXEMPT CE Yes Bearing PE
Load Type Inverter Type Speed Range NONE

Motor Wt. 30 LB Enclosure DP Lubrication POLYREX EM
Nameplate Mounting ROUND Rotation SELECTIVE CCW
Assembly Shaft Dia. Ext. Diag. D0000435-001
Cust Part No Outline E110382.00-S01 Ext. Diag2
Packaging F Outline Dash No Winding SS0054481
Carton Label GROUP : 3
