Industrial Motors

Leeson Electric E116706.00, 3 HP, 3500 RPM, 56C FR, 230 Vac, 1 PH, DP, General Purpose Motor.

Leeson Electric E116706.00, 3 HP, 3500 RPM, 56C FR, 230 Vac, 1 PH, DP, General Purpose Motor.

$1,094.00
$1,094.00
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.
$1,094.00 $590.76
Sale

E116706.00, 3 HP, 3500 RPM, 56C FR, 230 Vac, 1 PH, DP, General Purpose Motor.

Engineering Data

Output HP:3 Hp
Output KW:2.2 kW
Frequency:60 Hz
Voltage:230 V
Current:11.6 A
Speed:3450 rpm
Service Factor:1
Phase:1
Efficiency:84 %
Power Factor:99
Duty:Continuous
Insulation Class:F
Design Code:No Design Code
KVA Code:G
Frame:56C
Enclosure:Drip Proof
Thermal Protection:Automatic
Ambient Temperature:40 °C
Drive End Bearing Size:6203
Opp Drive End Bearing Size:6203
UL:No
CSA:N
CE:Y
IP Code:12
Technical Specifications
Electrical Type:Capacitor Start Capacitor Run
Starting Method:Across The Line
Poles:2
Rotation:Selective Clockwise
Resistance Main:.72 Ohms
Mounting:Round
Motor Orientation:HORIZONTAL
Drive End Bearing:BALL
Opp Drive End Bearing:BALL
Frame Material:Rolled Steel
Shaft Type:NEMA 56
Overall Length:13.58 in
Frame Length:7.75 in
Shaft Diameter:0.625 in
Shaft Extension:1.88 in
Assembly/Box Mounting:F1 Only
