Leeson Electric E116707.00, 3 HP, 3500 RPM, 56 FR, 230 Vac, 1 PH, DP, Rigid Base, General Purpose

E116707.00, 3 HP, 3500 RPM, 56 FR, 230 Vac, 1 PH, DP, Rigid Base, General Purpose

Engineering Data

Output HP:3 Hp
Output KW:2.2 kW
Frequency:60 Hz
Voltage:230 V
Current:11.6 A
Speed:3450 rpm
Service Factor:1
Phase:1
Efficiency:84 %
Power Factor:99
Duty:Continuous
Insulation Class:F
Design Code:No Design Code
KVA Code:G
Frame:56
Enclosure:Drip Proof
Thermal Protection:Manual
Ambient Temperature:40 °C
Drive End Bearing Size:6203
Opp Drive End Bearing Size:6203
UL:Recognized
CSA:Y
CE:N
IP Code:12
Technical Specifications
Electrical Type:Capacitor Start Capacitor Run
Starting Method:Across The Line
Poles:2
Rotation:Fixed Clockwise
Resistance Main:.72 Ohms
Mounting:Rigid base
Motor Orientation:HORIZONTAL
Drive End Bearing:BALL
Opp Drive End Bearing:BALL
Frame Material:Rolled Steel
Shaft Type:NEMA 56
Overall Length:13.50 in
Frame Length:7.75 in
Shaft Diameter:0.625 in
Shaft Extension:1.88 in
Assembly/Box Mounting:F1 Only
