Baldor Electric FPM2513T, 15 Hp, 1800 Rpm, 254T FR, 230/460 Vac, 3 PH, OPD, Fire Pump, Foot Mounted,

FPM2513T, 15 Hp, 1800 Rpm, 254T FR, 230/460 Vac, 3 PH, OPD, Fire Pump, Foot Mounted,

Engineering Data

Output 10.000 hp @ 50 Hz
15.000 hp @ 60 Hz
Phase 3
Synchronous Speed 1,500 rpm
Frequency 50.00 Hz
60.00 Hz
Voltage 190 V @ 50 Hz
380 V @ 50 Hz
230 V @ 60 Hz
460 V @ 60 Hz
Frame Material Steel
Frame 254T
XP Class and Group NONE
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals CSA EEV
UL
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 29.2 A @ 190 V
35.0 A @ 230 V
14.6 A @ 380 V
17.5 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 91.0%
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device No feedback
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 14.6 A
Insulation Class F
Inverter Code Inverter ready
KVA Code F
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit KO Box
Motor Lead Quantity/Wire Size 9 @ 12 AWG
Motor Lead Termination Flying Leads
Motor Standards NEMA
Motor Type 3936M
Number of Poles 4
Overall Length 21.69 in
Power Factor 87
Product Family FIRE PUMP MOTOR
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 1.625 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1,760 rpm
1,460 rpm
Speed Code Single Speed
Starting Method Direct on line
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
