Baldor Electric FPM2547TS, 60 Hp, 1800 Rpm, 364TS FR, 230/430 Vac, 3 PH, OPD, Fire Pump, Foot Mounted,

FPM2547TS, 60 Hp, 1800 Rpm, 364TS FR, 230/430 Vac, 3 PH, OPD, Fire Pump, Foot Mounted,

Engineering Data

Output 50.000 hp @ 50 Hz
60.000 hp @ 60 Hz
Phase 3
Synchronous Speed 1,800 rpm
Frequency 50.00 Hz
60.00 Hz
Voltage 190 V @ 50 Hz
380 V @ 50 Hz
230 V @ 60 Hz
460 V @ 60 Hz
Frame Material Steel
Frame 364TS
Brand Baldor-Reliance
Agency Approvals CSA
CSA EEV
UL
UR
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Blower None
Current 144.0 A @ 190 V
144.0 A @ 230 V
72.0 A @ 380 V
72.0 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 93.6%
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device No feedback
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No heater
High Voltage Full Load Amps 72.0 A
Insulation Class F
Inverter Code Not inverter
KVA Code F
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit KO Box
Motor Lead Quantity/Wire Size 12 @ 8 AWG
Motor Lead Termination Flying Leads
Motor Standards NEMA
Motor Type 4252M
Number of Poles 4
Overall Length 25.81 in
Power Factor 84
Product Family FIRE PUMP MOTOR
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 1.875 in
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1,770 rpm
1,470 rpm
Speed Code Single Speed
Starting Method Wye Start - Delta Run
Thermal Device - Bearing NONE (OLD)
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 None
Winding Thermal 2 None
