Baldor Electric FPM2568T-4, 300 Hp, 3600 Rpm, 445TS FR, 460 Vac, 3 PH, OPD, Fire Pump, Foot Mounted,

FPM2568T-4, 300 Hp, 3600 Rpm, 445TS FR, 460 Vac, 3 PH, OPD, Fire Pump, Foot Mounted,

Engineering Data

Output 250.000 hp @ 50 Hz
300.000 hp @ 60 Hz
Phase 3
Synchronous Speed 3,600 rpm
Frequency 50.00 Hz
60.00 Hz
Voltage 380 V @ 50 Hz
460 V @ 60 Hz
Frame Material Iron
Frame 445TS
XP Class and Group NONE
XP Division Not Applicable
Brand Baldor-Reliance
Agency Approvals CCSA US
CSA EEV
UL
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Base Indicator Rigid
Bearing Grease Type POLYREX EM (-20F +300F)
Current 342.0 A @ 380 V
339.0 A @ 460 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 95.0%
Feedback Device No feedback
Heater Indicator No heater
High Voltage Full Load Amps 339.0 A
Insulation Class F
Inverter Code Not inverter
KVA Code F
Lifting Lugs No Lifting Lugs
Motor Lead Quantity/Wire Size 12 @ 2 AWG
Motor Standards NEMA
Motor Type A44072M
Number of Poles 2
Overall Length 35.88 in
Power Factor 87
Product Family Other
Pulley End Bearing Type Ball
Pulley Face Code Standard
Service Factor 1.15
Shaft Diameter 2.375 in
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 3,560 rpm
2,960 rpm
Speed Code Single Speed
Starting Method Wye Start - Delta Run
Thermal Device - Bearing None
Thermal Device - Winding None
