FX13BK004, 1/3 HP, 1800 RPM, 56C FR, TEFC, 230/460 Vac, 3 PH, C-Face w/Removable Base, General Purpose, FLEX-IN-1

FX13BK004, 1/3 HP, 1800 RPM, 56C FR, TEFC, 230/460 Vac, 3 PH, C-Face w/Removable Base, General Purpose, FLEX-IN-1 Engineering Data Volts 208-230 Volts 460 Volts 190/380 F.L. Amps 1.3 F.L. Amps .65 F.L. Amps 1.5/.75 S. F Amps 1.5 S. F Amps .75 S. F Amps 1.7/.85 RPM 1800 Hertz 60/50 HP 1/3 Duty CONTINUOUS TYPE TF KW 0.25 Frame S56C Serv. Factor 1.25 Phase 3 Max Amb 40 Design NO DESIGN CODE Code M Insul Class F Protection NOT Therm.Prot. 7AM035A5 Eff 100% 77 Eff 75% PF 60 UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203 CC Number EXEMPT CE Yes Bearing PE 6203 Load Type Inverter Type Speed Range NONE Motor Wt. 20 LB Enclosure TEFC Lubrication VERIFY Nameplate A-92005-19 Mounting ROUND Rotation REV Assembly LO102696 Shaft Dia. 5/8 IN Ext. Diag. 005010.20 Cust Part No Outline 031637-550 Ext. Diag2 Packaging B Outline Dash No Winding TE48462 Carton Label Leeson Wattsaver GROUP : 3
