Industrial Motors

Marathon Electric H1668, 5 Hp, 1800 Rpm, 184T FR, 200 Vac, 3 PH, TEFC, Rigid Base, General Purpose, Standard Efficiency, 184TTFR7727

Marathon Electric H1668, 5 Hp, 1800 Rpm, 184T FR, 200 Vac, 3 PH, TEFC, Rigid Base, General Purpose, Standard Efficiency, 184TTFR7727

$1,073.00
$1,073.00
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.
$1,073.00 $1,019.35
Sale

**This motor has been replaced by Model# E2163**
H1668, 5 Hp, 1800 Rpm, 184T FR, 200 Vac, 3 PH, TEFC, Rigid Base, General Purpose, Standard Efficiency, 184TTFR7727.

Engineering Data

60 Hertz
HP 5 Voltage 200
kW 3.70 FL Amps 15
RPM 1800
FL Eff 87.5 % SF 1.15

Phase 3 Insulation Class F
Frame 184T Duty CONTINUOUS
Enclosure TEFC Ambient 40
Mounting Rigid NEMA Design B
Orientation HORIZONTAL Starting Type ACROSS THE LINE
Assembly F1 ONLY KVA Code J
Drive End Bearing BALL IP Code 43
Opposite End Bearing BALL
Drive End Bearing Size 6206
Opposite End Bearing Size 6205
Weight 75 LB lbs
CE Y CSA Y
UL Recognized Construction
Thermal Protection
