Leeson Electric 103794.00, 1/3 HP, 1800 RPM, S56 FR, 115 Vac, 1 PH, DP, Instant Reversing Motor, Resilient Base.

103794.00, 1/3 HP, 1800 RPM, S56 FR, 115 Vac, 1 PH, DP, Instant Reversing Motor, Resilient Base.

Engineering Data

Output HP:0.33 Hp
Output KW:0.25 kW
Frequency:60/50 Hz
Voltage:115 V
Current:4.2 A
Speed:1625 rpm
Service Factor:1
Phase:1
Efficiency:53 %
Power Factor:96
Duty:60 Minute
Insulation Class:B
Design Code:N
KVA Code:A
Frame:S56
Enclosure:Drip Proof
Thermal Protection:Manual
Ambient Temperature:40 °C
Drive End Bearing Size:6203
Opp Drive End Bearing Size:6203
UL:Recognized
CSA:Y
CE:N
IP Code:12
Technical Specifications
Electrical Type:Permanent Split Capacitor
Starting Method:Across The Line
Poles:4
Rotation:Selective Counterclockwise
Resistance Main:2.79 Ohms
Mounting:Resilient Base
Motor Orientation:Horizontal
Drive End Bearing:Ball
Opp Drive End Bearing:Ball
Frame Material:Rolled Steel
Shaft Type:NEMA 56
Overall Length:10.81 in
Frame Length:6.00 in
Shaft Diameter:0.625 in
Shaft Extension:1.88 in
Assembly/Box Mounting:F1 ONLY
