Marathon Electric B320, 056S17D2055, 1/3 Hp, 1725 RPM, 56CZ FR, 115 V, 1 PH, Dripproof , C-Face Footless, Exhaust Ventilator

Marathon Electric B320, 056S17D2055, 1/3 Hp, 1725 RPM, 56CZ FR, 115 V, 1 PH, Dripproof , C-Face Footless, Exhaust Ventilator

General Specifications

Model : 056S17D2055
Catalog No : B320
Part Description : 1/3,1725,DP,56CZ,1/60/115 (USE 5KH35JN121)
Category : Single Phase
Stock : No

Nameplate Specifications

Output HP : 0.33 Hp
Output KW : 0.25 kW
Frequency : 60 Hz
Voltage : 115 V
Current : 6.1 A
Speed : 1725 rpm
Service Factor : 1.35
Phases : 1
Efficiency : 62 %
Duty : CONTINUOUS
Insulation Class : B
Design Code : NO DESIGN CODE
KVA Code : M
Frame : 56CZ
Enclosure : DP
Overload Protector : NOT
Ambient Temperature : 40 °C
Drive End Bearing Size : 6203
Opp Drive End Bearing Size : 6203
UL : Recognized
CSA : Y
CE : N IP Code : 22

Technical Specifications

Electrical Type : SPLIT PHASE
Starting Method : ACROSS THE LINE
Poles : 4
Rotation : SELECTIVE CCW
Mounting : ROUND
Motor Orientation : HORIZONTAL
Drive End Bearing : BALL
Opp Drive End Bearing : BALL
Frame Material : ROLLED STEEL
Shaft Type : SGL SPL EXT
Overall Length : 10.56 in
Frame Length : 6.25 in
Shaft Diameter : 0.63 in
Shaft Extension : 2.44 in
Assembly/Box Mounting : F1 ONLY
