Marathon Electric CG201, 1/4 HP, 1725 RPM, 48 FR, 115 V, 1 PH, Dripproof, Resilient Base, Fan & Blower, 5KC35JN12X

CG201, 1/4 HP, 1725 RPM, 48 FR, 115 V, 1 PH, Dripproof, Resilient Base, Fan & Blower, 5KC35JN12X

Engineering Data

Model : 5KC35JN12X
Catalog No : CG201
Part Description : 1/4,1725,DP,48,1/60/115
Category : Open Drip Proof (ODP)
Stock : No

Nameplate Specifications

Output HP : 0.25 Hp
Output KW : 0.19 kW
Frequency : 60 Hz
Voltage : 115 V
Current : 5.2 A
Speed : 1725 rpm
Service Factor : 1.35
Phases : 1
Efficiency : 58.4 %
Duty : CONT
Insulation Class : B
KVA Code : M
Frame : 48
Enclosure : DP
Overload Protector : AUTO
Ambient Temperature : 40 °C
Drive End Bearing Size : 6203
Opp Drive End Bearing Size : 6203
UL : Recognized
CSA : Yes
CE : N

Technical Specifications

Electrical Type : Capacitor start(CSIR)
Starting Method : SM
Poles : 4
Rotation : CCW/CW
Mounting : RB
Motor Orientation : ANY
Drive End Bearing : BALL
Opp Drive End Bearing : BALL
Frame Material : Rolled Steel
Overall Length : 9.57 in
Frame Length : 5.79 in
Shaft Diameter : 0.5 in
Shaft Extension : 1.5 in
UPC : 722856007414
Weight : 16.00 LB
