Marathon Electric X077, 1 1/2 Hp, 1140 Rpm, 56Y FR, 200-230/460 Vac, 3 PH, C-Face Footless, OPAO, Multi-Power, Fan & Blower, Direct Drive, Resilient Base, 048A11O11066

X077, 1 1/2 Hp, 1140 Rpm, 56Y FR, 200-230/460 Vac, 3 PH, C-Face Footless, OPAO, Multi-Power, Fan & Blower, Direct Drive, Resilient Base, 048A11O11066

Engineering Data

Nameplate Specifications

Output HP  0.5 Hp
Output KW  0.37 kW
Frequency  60 Hz
Voltage  115 V
Current  6.1 ASpeed  1075 rpm
Service Factor  1
Phases  1
Efficiency  64 %
Duty  CONTINUOUS
Insulation Class  B
Design Code  NO DESIGN CODE
KVA Code  A
Frame  48Y
Enclosure  OPAO
Overload Protector  AUT LCK RTR ONLY
Ambient Temperature  40 °C
Drive End Bearing Size  6203
Opp Drive End Bearing Size  6203
UL  Recognized
CSA  N
CE  N
IP Code  10

Technical Specifications

Electrical Type  PSC 4 SPEED
Starting Method  ACROSS THE LINE
Poles  6
Rotation  SELECTIVE CCW
Mounting  RESILIENT RING-EXTENDED STUDS
Motor Orientation  HORIZONTAL
Drive End Bearing  BALL
Opp Drive End Bearing  BALL
Frame Material  ROLLED STEEL
Shaft Type  SGL SPL EXT
Overall Length 11 in
Frame Length  4.5 in
Shaft Diameter  0.5 in
Shaft Extension  5.06 in
Assembly/Box Mounting  F1 ONLY
