KB Electronics SI-6 (9444), KBMM Signal Isolator Board (SI-6)

KB Electronics SI-6 (9444), KBMM Signal Isolator Board (SI-6)

$141.00
$141.00
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.
$141.00 $97.29
Sale

SI-6 (9444), KBMM Signal Isolator Board (SI-6).

The SI-5 and SI-6 Barrier Terminal Board Signal Isolators convert standard KBIC® and KBMM™ controls to an isolated input. By using external resistors, the input signal can be changed to 0-100VDC, 0-200VDC and 4-20mA. The output voltage is 0-10VDC which can be rescaled via the built-in Min and Max trimpots. Selectable AC line jumpers allow the SI-5 and SI-6 to be used either with 115 or 230VAC controls. Installation is made by simply mating the unit to the speed control via the built-in quick-connect terminals.

Models where used:
KBMM
KBIC
