Baldor Electric VEM3711T, 10 Hp, 3600 Rpm, 213TC FR, 230/460 Vac, 3 PH, TEFC, C-Face Footless, General Purpose Motor

VEM3711T, 10 Hp, 3600 Rpm, 213TC Fr, 230/460 Vac, 3 PH, TEFC, C-Face Footless, General Purpose Motor.

Engineering Data

Output 10.000 hp

Phase 3

Synchronous Speed 3,600 rpm

Frequency 60 Hz

Voltage 230 V
460 V

Enclosure TEFC

Frame Material Steel

Frame 215TC

XP Class and Group NONE

XP Division Not Applicable

Brand Baldor-Reliance

Agency Approvals CSA
CSA EEV
UR

Ambient Temperature 40 °C

Auxillary Box No Auxillary Box

Auxillary Box Lead Termination None

Base Indicator No Mounting

Bearing Grease Type POLYREX EM (-20F +300F)

Blower None

Current 24.8 A @ 208 V
24.2 A @ 230 V
12.1 A @ 460 V

Design Code A

Drip Cover No Drip Cover

Duty Rating CONT

Efficiency @ 100% Load 90.2%

Electrically Isolated Bearing No electrically isolated

Feedback Device No feedback

Front Face Code Standard

Front Shaft Indicator None

Heater Indicator No heater

High Voltage Full Load Amps 12.1 A

Insulation Class F

Inverter Code Inverter ready

KVA Code J

Lifting Lugs Std Lifting Lugs

Locked Bearing Indicator Locked Bearing

Motor Lead Exit KO Box

Motor Lead Quantity/Wire Size 9 @ 14 AWG

Motor Lead Termination Flying Leads

Motor Standards NEMA

Motor Type 3732M

Number of Poles 2

Overall Length 18.63 in

Power Factor 84

Product Family General Purpose

Pulley End Bearing Type Ball Bearing

Pulley Face Code C-Face

Pulley Shaft Indicator Standard

Rodent Screen No Rodent Screen

Service Factor 1.15

Shaft Diameter 1.375 in

Shaft Extension Location Pulley End

Shaft Ground Indicator No Shaft Grounding

Shaft Rotation Reversible

Shaft Slinger Indicator No Slinger

Speed 3,490 rpm

Speed Code Single Speed

Starting Method DOL

Thermal Device - Bearing None

Thermal Device - Winding None

Vibration Sensor Indicator No Vibration Sensor

Winding Thermal 1 None

Winding Thermal 2 None
