Weg Electric 00736OS1C184T, 7 1/2 Hp, 3600 Rpm, 182/4T Frame, 208-230Vac, TEFC, 3 PH, Foot-mounted, Rolled Steel.

00736OS1C184T, 7 1/2 Hp, 3600 Rpm, 182/4T Frame, 208-230Vac, TEFC, 3 PH, Foot-mounted, Rolled Steel.

Engineering Data

Standard NEMA MG-1
Frequency 60 Hz
Voltage 208-230 V
Number of poles 2
Synchronous speed 3600 rpm
Output rating 7.5 HP
Mounting Foot-mounted
Flange Without
Mounting F-1
Terminal box¹ Left position
Enclosure IC01 - ODP

Frame 182/4T
Output 7.5 HP (5.5 kW)
Number of Poles 2
Frequency 60 Hz
Rated speed 3500 rpm
Slip 2.78 %
Rated voltage 208-230 V
Rated current 31.8-28.5 A
L. R. Amperes 219-197 A
LRC 6.9x(Code G)
No load current 4.14-4.80 A
Rated torque 11.3 ft.lb
Locked rotor torque 280 %
Breakdown torque 254 %
Locked rotor time 10s (cold) 6s (hot)
Moment of inertia (J) 0.1991 sq.ft.lb
Design L
Insulation Class F
Temperature rise 80 K
Service factor 1.15 (1.00 @ 208V)
Duty Cycle Cont.(S1)
Starting Method Direct On Line
Ambient temperature -20°C to +40°C
Altitude 1000 m.a.s.l.
Enclosure IC01 - ODP
Mounting F-1
Rotation¹ Both (CW and CCW)
