Weg Electric 1313017157, 2 Hp, 3600/3000 Rpm, 56C Frame, 230/460 Vac, TEFC, Footless, Washdown NEMA Premium Efficiency.

1313017157, 2 Hp, 3600/3000 Rpm, 56C Frame, 230/460 Vac, TEFC, Footless, Washdown NEMA Premium Efficiency.

Engineering Data

Standard NEMA MG-1
Frame 56C
Frequency 60/50 Hz
Number of poles 2
Degree of Protection IP66
Synchronous speed 3600/3000 rpm
Mounting Footless
Flange C
Mounting F-1
Terminal box¹ Left position
Enclosure TEFC

Standard NEMA MG-1
Degree of Protection IP66
Mounting F-1
Output rating 2 HP
Enclosure TEFC
Frequency 60/50 Hz
Flange C
Frame Material Stainless steel
Mounting Footless
Efficiency NEMA Premium Efficiency
Motor Application HydroDuty
Terminal box¹ Left position
Frame 56C
Voltage 230/460 V
Synchronous speed 3600/3000 rpm
Number of Poles 2
