Industrial Motors

Marathon Electric K630, 3/4 Hp, 3600 Rpm, 56J FR, 208-230/460 Vac, 3 PH, Totally Enclosed, C-Face Footed, Removable Base, Centrifugal Pump (Jet Pump), 5K36MN4157

Marathon Electric K630, 3/4 Hp, 3600 Rpm, 56J FR, 208-230/460 Vac, 3 PH, Totally Enclosed, C-Face Footed, Removable Base, Centrifugal Pump (Jet Pump), 5K36MN4157

$270.00
$270.00
Add to Cart for Discount
Sale Sold out
Shipping calculated at checkout.
Marathon Electric Motors is no longer manufacturing this motor, possible replacement is the following Marathon Electric Motors part# J062

**This motor has been replaced by Model# J062**
K630, 3/4 Hp, 3600 Rpm, 56J FR, 208-230/460 Vac, 3 PH, Totally Enclosed, C-Face Footed, Removable Base, Centrifugal Pump (Jet Pump), 5K36MN4157

Engineering Data

60/50 Hertz
HP 3/4 Voltage 208-220/440
kW N/A FL Amps 2.8-2.9/1.5
RPM 3450/2850
FL Eff 0 % SF 1

Phase 3 Insulation Class B
Frame N/A Duty Continuous
Enclosure TEFC Ambient 40
Mounting WB NEMA Design
Orientation Horizontal or Vertical Starting Type Squirrel Cage Induction
Assembly N/A KVA Code M
Drive End Bearing BALL IP Code N/A
Opposite End Bearing BALL
Drive End Bearing Size 17MM
Opposite End Bearing Size Hazardous Location N/R
Weight 20.6 LB lbs
CE N/A CSA N/A
UL Y
Thermal Protection None
