Leeson Electric 141428.00, 7 1/2 Hp, 1800 Rpm, 215T FR, 230 Vac, 1 PH, TEFC, Rigid Base, General Purpose Motor.

141428.00, 7 1/2 Hp, 1800 Rpm, 215T FR, 230 Vac, 1 PH, TEFC, Rigid Base, General Purpose Motor.

Engineering Data

Output HP:7.50 Hp
Output KW:5.6 kW
Frequency:60 Hz
Voltage:230 V
Current:30.5 A
Speed:1750 rpm
Service Factor:1.15
Phase:1
Efficiency:85.5 %
Power Factor:95
Duty:Continuous
Insulation Class:F
Design Code:No Design Code
KVA Code:K
Frame:215T
Enclosure:Totally Enclosed Fan Cooled
Thermal Protection:No
Ambient Temperature:40 °C
Drive End Bearing Size:6307
Opp Drive End Bearing Size:6206
UL:Recognized
CSA:Y
CE:N
IP Code:43
Technical Specifications
Electrical Type:Capacitor Start Capacitor Run
Starting Method:Across The Line
Poles:4
Rotation:Selective Counterclockwise
Resistance Main:.215 Ohms
Mounting:Rigid base
Motor Orientation:Horizontal
Drive End Bearing:Ball
Opp Drive End Bearing:Ball
Frame Material:Rolled Steel
Shaft Type:T
Overall Length:21.09 in
Frame Length:12.40 in
Shaft Diameter:1.375 in
Shaft Extension:3.5 in
Assembly/Box Mounting:F1 Only
