Leeson Electric 141430.00, 10 Hp, 1800 Rpm, 215T FR, 208-230 Vac, 1 PH, Open Drip Proof, Rigid Base, Air Compressor, General Purpose Motor

141430.00, 10 Hp, 1800 Rpm, 215T FR, 208-230 Vac, 1 PH, Open Drip Proof, Rigid Base, Air Compressor, No Overload, General Purpose Motor

Engineering Data

Output HP : 10 HP
Output KW : 7.5 kW
Frequency : 60 Hz
Voltage : 208-230 V
Current : 49.0-44.0 A
Speed : 1730 RPM
Service Factor : 1.15
Phase : 1
Efficiency : 82.5 %
Duty : Continous
Insulation Class : F
Design Code : L KVA
Code : G
Frame : 215T
Enclosure : Drip Proof
Overload Protector : No
Ambient Temperature : 40 °C
Drive End Bearing Size : 6307
Opp Drive End Bearing Size : 6206
UL : Recognized
CSA : Y CE : Y IP Code : 22
Technical Specifications
Electrical Type : Capacitor Start Capacitor Run
Starting Method : Across The Line
Poles : 4
Rotation : Selective Counterclockwise
Mounting : Rigid Base
Motor Orientation : Horizontal
Drive End Bearing : Ball
Opp Drive End Bearing : Ball
Frame Material : Rolled Steel
Shaft Type : T
Overall Length : 19.29 in
Frame Length : 12.40 in
Shaft Diameter : 1.375 in
Shaft Extension : 3.47 in
Assembly/Box Mounting : F1 Only
