Leeson Electric 141431.00, 10 Hp, 1800 Rpm, 215JM FR, 230 Vac, 1 PH, DP, Rigid Base, General Purpose Motor

141431.00, 10 Hp, 1800 Rpm, 215JM FR, 230 Vac, 1 PH, DP, Rigid Base, General Purpose Motor

Engineering Data

Output HP:10 Hp
Output KW:7.5 kW
Frequency:60 Hz
Voltage:230 V
Current:39.0 A
Speed:1745 rpm
Service Factor:1.15
Phase:1
Efficiency:86.5 %
Power Factor:96.4
Duty:Continuous
Insulation Class:F
Design Code:L
KVA Code:G
Frame:215JM
Enclosure:Drip Proof
Thermal Protection:No
Ambient Temperature:40 °C
Drive End Bearing Size:6309
Opp Drive End Bearing Size:6206
UL:Recognized
CSA:Y
CE:Y
IP Code:12
Technical Specifications
Electrical Type:Capacitor Start Capacitor Run
Starting Method:Across The Line
Poles:4
Rotation:Selective Counterclockwise
Resistance Main:0 Ohms
Mounting:Rigid base
Motor Orientation:Horizontal
Drive End Bearing:Ball
Opp Drive End Bearing:Ball
Frame Material:Rolled Steel
Shaft Type:JM
Overall Length:21.17 in
Frame Length:12.40 in
Shaft Diameter:1.125 in
Shaft Extension:4.5 in
Assembly/Box Mounting:F1 Only
