Marathon Electric C460, 1/4 HP, 1500 RPM, 48 FR, 110/220 Vac, 1 PH, Dripproof , Resilient Base, Fan & Blower, 5KC36LN19X.

C460, 1/4 HP, 1500 RPM, 48 FR, 110/220 Vac, 1 PH, Dripproof , Resilient Base, Fan & Blower, 5KC36LN19X.

General Specifications

Model : 5KC36LN19X
Catalog No : C460
Part Description : 1/4 Hp ,1 Ph , 110/220 V ,1425 RPM , AC Motor
Category : Open Drip Proof (ODP)
Stock : Yes

Nameplate Specifications

Output HP : 0.25 Hp
Output KW : 0.19 kW
Frequency : 50 Hz
Voltage : 110/220 V
Current : 5.6,2.8 A
Speed : 1425 rpm
Service Factor : 1.35
Phases : 1
Efficiency : 59.5 %
Duty : CONT
Insulation Class : B
KVA Code : N
Frame : 48
Enclosure : DP
Overload Protector : AUTO
Ambient Temperature : 40 °C
Drive End Bearing Size : 6203
Opp Drive End Bearing Size : 6203
UL : Recognized
CSA : Yes
CE : N

Technical Specifications

Electrical Type : Capacitor start(CSIR)
Starting Method : SM
Poles : 4
Rotation : CCW/CW
Mounting : RB
Motor Orientation : ANY
Drive End Bearing : BALL
Opp Drive End Bearing : BALL
Frame Material : Rolled Steel
Overall Length : 10 in
Frame Length : 6.22 in
Shaft Diameter : 0.5 in
Shaft Extension : 1.5 in
UPC : 722856007384
Weight : 18.00 LB
